EXCLUSIVE
MODEL 2402
Studio Monitor Speaker System
   MODEL 2402 is designed for use in relatively small studio control or editing rooms. It combines the TL-1601a low-frequency loudspeaker, TD-4001 high frequency driver, TH-4001 stabilized dispersion horn and TN-2 dividing network. High resolution across a wide range, a high maximum sound pressure level and wide latitude in placement are its distinctive attributes. Like the 2401, this studio monitor features superior transient response and a uniform dispersion pattern. It too meets the critical demands of professionals.

Speaker Components

  • TL-1601a  low frequency loudspeaker
  • TD-4001   high frequency compression driver
  • TH-4001   high frequency horn

MODEL 2252 SPECIFICATIONS

Dividing Network TN-1
Impedence 8ohm
Reproduct. Freq. Zon 29-20,000 Hz
Input Capacity 150W Rated, 300W Max
Output Sound Pressure Level 95db
Max Output Sound Pressure Level 120db(1m)
Crossover Frequency 650Hz
Dimensions (WxHxD) 26 x 31-7/16x24-3/16 inches/660 x 798 x 614 mm (enclosure depth: 18-7/8 inches/480mm)
Weight 93kg
